Question: What is the minimum distance between a node & an antinode in a standing wave?...

What is the minimum distance between a node & an antinode in a standing wave?

A

L2/nL^2/n

B

2Ln2Ln

C

2L/n2L/n

D

n/Ln/L

Answer

2L/n (assuming a flawed question where it implicitly asks for wavelength or has a typo)

Explanation

Solution

The minimum distance between a node and an antinode in a standing wave is always one-quarter of the wavelength (λ/4\lambda/4). For a string fixed at both ends or an open organ pipe, the wavelength of the nn-th harmonic is λn=2L/n\lambda_n = 2L/n. Therefore, the minimum distance between a node and an antinode would be λn4=14(2Ln)=L2n\frac{\lambda_n}{4} = \frac{1}{4} \left(\frac{2L}{n}\right) = \frac{L}{2n}. For a closed organ pipe, the wavelength for the nn-th odd harmonic is λn=4L/n\lambda_n = 4L/n, and the minimum distance is λn4=14(4Ln)=Ln\frac{\lambda_n}{4} = \frac{1}{4} \left(\frac{4L}{n}\right) = \frac{L}{n}. None of the provided options (L2/nL^2/n, 2Ln2Ln, 2L/n2L/n, n/Ln/L) match these standard results. The option 2L/n2L/n represents the wavelength itself for a string fixed at both ends or an open pipe, not the distance between a node and an antinode. The question as stated with the given options is flawed.
