Question
Question: The accompanying figure represents an ecological pyramid. It is  is incorrect. Pyramid of numbers in a grassland will always be upright. This is because, in a grassland the producers are grasses which are huge in number compared to the herbivores or carnivores present. Thus, the number of animals in each trophic level goes on decreasing as we move towards the apex predators. Thus, a grassland ecosystem will always have an upright pyramid of biomass.
Option (b) is incorrect. The pyramid of biomass in a fallow land is also erect, since the producers outnumber the consumer levels of the ecosystem.
Option (c) is correct. In a lake, the phytoplankton form the producer levels. The number of phytoplankton is always less than the number of consumers in a lake. Since, the phytoplankton are short lived they do not contribute hugely to the biomass. Hence, the pyramid of biomass in a lake is always inverted.
Option (d) is incorrect. According to Lindeman’s 10 percent rule, only 10 percent of the energy received by a trophic level can be passed on to the next level. The producer level being the energy trapping level receives the maximum amount of energy. The amount of energy passed on to the herbivore level is 10 percent of the energy trapped by producers. The herbivores, in turn, pass on 10 percent of the amount of energy received to the carnivore level. Hence, the amount of energy passed on to higher trophic levels goes on decreasing and thus the pyramid of energy is always upright.
Hence, the correct answer is option (C).
Note: Ecological pyramids delineate relationships between different trophic levels in an ecosystem. Biomass is the amount of organic matter produced at each of the trophic levels in an ecosystem. The pyramid of biomass indicates the relationship between biomass and trophic levels. It is always inverted in lakes because the producer level cannot outnumber the consumer levels.
