Question

A cyclotron is operated with a magnetic field of strength 2.1 T. Calculate the frequency in which the electric field between two dees could be reversed.

• A. 15.6MHz
• B. 21.6MHz
• C. 7.5MHz
• D. 30.6MHz

Answer 1

Answer: (D)

30.6MHz

Answer 2

The frequency at which the electric field between the dees of a cyclotron is reversed is known as the cyclotron frequency or resonant frequency. This frequency is given by the formula:

$f = \frac{qB}{2\pi m}$

Where:

• $f$ is the cyclotron frequency (in Hz)
• $q$ is the charge of the particle being accelerated (for a proton, $q = 1.602 \times 10^{-19}$ C)
• $B$ is the magnetic field strength (given as 2.1 T)
• $m$ is the mass of the particle being accelerated (for a proton, $m = 1.672 \times 10^{-27}$ kg)

Assuming the cyclotron is used to accelerate protons, we substitute the given values and constants:

$B = 2.1 \text{ T}$ $q = 1.602 \times 10^{-19} \text{ C}$ $m = 1.672 \times 10^{-27} \text{ kg}$ $\pi \approx 3.14159$

Now, calculate the frequency:

$f = \frac{(1.602 \times 10^{-19} \text{ C}) \times (2.1 \text{ T})}{2 \times 3.14159 \times (1.672 \times 10^{-27} \text{ kg})}$

$f = \frac{3.3642 \times 10^{-19}}{10.5057 \times 10^{-27}}$

$f = 0.32022 \times 10^8 \text{ Hz}$

$f = 32.022 \times 10^6 \text{ Hz}$

$f = 32.022 \text{ MHz}$

The calculated frequency of 32.022 MHz is closest to 30.6 MHz. The slight difference might be due to rounding of constants or options in the problem.
