Question: A particle is given a velocity at the bottom most position in a smooth spherical shell of radius 2m....

Question

A particle is given a velocity at the bottom most position in a smooth spherical shell of radius 2m.] just complete a vertical circular motion. Then

Answer 1

Solution

The problem asks us to find the acceleration of a particle at different points in a smooth spherical shell of radius R = 2m, given that it just completes a vertical circular motion.

First, let's establish the necessary velocities at key points for a particle to just complete a vertical circular motion in a smooth spherical shell. Let the bottom-most point be A, the top-most point be C, and the points at the same level as the center be B (on the left) and D (on the right).

Velocity at the top-most point (C): For the particle to just complete the circle, the normal force at the top (C) must be zero. The centripetal force is provided solely by gravity. $mg = \frac{mv_C^2}{R} \implies v_C^2 = gR$ Given R = 2m, $v_C^2 = 2g$ .
Velocity at the bottom-most point (A): Using the conservation of mechanical energy between A and C (taking A as the reference level for potential energy, h=0): $\frac{1}{2}mv_A^2 + mg(0) = \frac{1}{2}mv_C^2 + mg(2R)$ $\frac{1}{2}mv_A^2 = \frac{1}{2}m(gR) + 2mgR = \frac{5}{2}mgR$ $v_A^2 = 5gR$ Given R = 2m, $v_A^2 = 5g(2) = 10g$ .
Velocity at points B/D (at the level of the center): Using the conservation of mechanical energy between A and B (height of B is R from A): $\frac{1}{2}mv_A^2 = \frac{1}{2}mv_B^2 + mgR$ $\frac{1}{2}m(5gR) = \frac{1}{2}mv_B^2 + mgR$ $\frac{5}{2}mgR - mgR = \frac{1}{2}mv_B^2$ $\frac{3}{2}mgR = \frac{1}{2}mv_B^2$ $v_B^2 = 3gR$ Given R = 2m, $v_B^2 = 3g(2) = 6g$ .

Now, let's evaluate the acceleration at the points mentioned in the options:

Acceleration at the bottom-most point (A): At A, the velocity is purely vertically upward. The only acceleration is centripetal acceleration, directed upwards (towards the center). There is no tangential acceleration as gravity is perpendicular to the velocity. $a_A = a_c = \frac{v_A^2}{R} = \frac{5gR}{R} = 5g$ .
Acceleration at the top-most point (C): At C, the velocity is purely vertically downward. The only acceleration is centripetal acceleration, directed downwards (towards the center). There is no tangential acceleration. $a_C = a_c = \frac{v_C^2}{R} = \frac{gR}{R} = g$ .
Acceleration at points B/D (at the level of the center): At B/D, the velocity is horizontal. The acceleration has two components:
1. Centripetal acceleration ( $a_c$ ): Directed horizontally towards the center. $a_c = \frac{v_B^2}{R} = \frac{3gR}{R} = 3g$ .
2. Tangential acceleration ( $a_t$ ): Gravity acts vertically downwards. At B/D, the tangent is vertical. So, the component of gravity along the tangent is $g$ . $a_t = g$ . The total acceleration is the vector sum of these perpendicular components: $a_{B/D} = \sqrt{a_c^2 + a_t^2} = \sqrt{(3g)^2 + g^2} = \sqrt{9g^2 + g^2} = \sqrt{10g^2} = g\sqrt{10}$ .

Now let's check each option:

(A) acceleration of particle when the velocity of the particle is in vertically upward direction is $g\sqrt{10}$ Strictly, "velocity is in vertically upward direction" occurs at the bottom-most point (A). At A, the acceleration is $5g$ . So, this statement is incorrect if interpreted strictly. However, in problems involving vertical circular motion, the phrase "velocity is vertical" or "velocity is horizontal" is sometimes ambiguously used. The similar question provided uses "velocity is vertical at point B" (where B is at the horizontal diameter, and velocity is horizontal) and calculates the acceleration as $g\sqrt{10}$ . Following this common (though confusing) convention, if "velocity is in vertically upward direction" refers to the point where the velocity is horizontal (i.e., at B or D), then the acceleration is indeed $g\sqrt{10}$ . Given the context of the similar question, this interpretation is likely intended. So, assuming this interpretation, option (A) is correct.

(B) acceleration of particle when the velocity of the particle is in vertically downward direction is $\sqrt{10}$ Strictly, "velocity is in vertically downward direction" occurs at the top-most point (C). At C, the acceleration is $g$ . So, $g\sqrt{10}$ would be incorrect. Furthermore, the value given is $\sqrt{10}$ , which is dimensionally incorrect (missing 'g'). So, option (B) is incorrect.

(C) acceleration of the particle at the top most point of path is g As calculated, at the top-most point (C), the acceleration is $g$ . This statement is correct.

(D) acceleration of the particle at the bottom most point is 5g As calculated, at the bottom-most point (A), the acceleration is $5g$ . This statement is correct.

Based on our analysis, options (C) and (D) are unambiguously correct. Option (A) is correct if we adopt the common, albeit imprecise, phrasing often found in such problems (as seen in the similar question). If this is a single-choice question, there might be an error in the question as multiple options appear correct. However, if multiple options can be correct, then (A), (C), and (D) are correct. Assuming the question expects all correct options, we list all three.

The most common point of interest for acceleration other than top/bottom is the point at the horizontal diameter. The value $g\sqrt{10}$ corresponds to this point. The phrasing in (A) is very likely an attempt to describe this point.

Final Answer Check: R = 2m. $v_A^2 = 10g \implies a_A = 5g$ . (D is correct) $v_C^2 = 2g \implies a_C = g$ . (C is correct) $v_B^2 = 6g \implies a_B = \sqrt{(3g)^2 + g^2} = g\sqrt{10}$ . (A is correct under the interpretation that "velocity is in vertically upward direction" refers to the point where velocity is horizontal).

Since the similar question provided has option A as the correct answer (which calculates acceleration at the point where velocity is horizontal), and the value is $g\sqrt{10}$ , it is highly probable that option A is also intended to be correct in this question, despite the poor phrasing.
