Question

Question: A sinusoideal voltage forms value 220 V is applied to a diode and a resistor R in the circuit shown ...

A sinusoideal voltage forms value 220 V is applied to a diode and a resistor R in the circuit shown in figure, so that half wave rectification occurs, if the diode is ideal, what is rms voltage acrossR1R_{1}?

A

552V55\sqrt{2}V

B

1.10V1.10V

C

1102V110\sqrt{2}V

D

2202V220\sqrt{2}V

Answer

2202V220\sqrt{2}V

Explanation

Solution

: 2202V220\sqrt{2}V
